RV Diesel Generators are the perfect addition to your home or vehicle. A fully portable RV Diesel Generators are all built with high quality and a powerful, fuel efficient engine making them cost effective.
Our RV Diesel Generators are designed for the unique demands of RV and commercial applications. H-GV 10000i RV Diesel Generators are the perfect choice for extended outdoor events, engineered to deliver longer run times, higher power output and greater efficiency.
| Generator sets | |
| Model | H-GV 10000i |
| Rated frequency (Hz) | 50/60 |
| Rated voltage (V) | 230/120 |
| Waveform distortion rate (%) | ≤3% |
| Rated output (KVA) | 8 |
| Maximum output (KVA) | 10 |
| Rotational speed (rpm) | 2200-2800 |
| Noise level (dBa/7m) | 54 |
| Dimensions (LxWxH) (mm) | 720*545*600 |
| Net weight (Kg) | 171 |
| Engines | |
| Engine brands | Kubota |
| Engine type | D722 |
| Number of cylinders | Three cylinders |
| Discharge volume (CC) | 719 |
| Bore x stroke (mm) | 67*68 |
| Cooling systems | Indirect water cooling |
| Fuels | Light Diesel |
| Fuel consumption (L/hr) | 1.2-3 |
| Lubricating oil capacity (L) | 3.8 |
| Control systems | |
| Start-up system | One-touch electric start + remote start |
| Start the battery | 12VDC |
| Remote control panel | With digital display and alarm |
| Inverter | Split |
| Throttle control | Automatic |
| Dampers control | Automatic |
| Other functions | |
| Overload protection | Yes |
| Short circuit protection | Yes |
| Temperature protection | Yes |
| Oil shortage alarm | Yes |
| Petrol oil level alarm | Yes |
| Parallel function | Optional |
| Automatic changeover switches | Yes |
